Energy class

D

Venting tube diameter

12 cm

Colour of housing/chimney

grey

Lightning efficiency class

C

Material of housing/chimney

varnished steel

Fluid dynamic efficiency class

E

Grease filtering efficiency class

D

Maximum extraction rate by extraction operation

370 m³/h

Maximum extraction rate by recirculation operation

140 m³/h

Lamp type

LED

Control setting

Switch

Power of lights

6 W

Number of lights

2

Number of speed positions

3

Air flow by extraction version, step 1

290 m³/h

Air flow by extraction version, step 2

340 m³/h

Air flow by extraction version, step 3

370 m³/h

Height

208 mm

EAN code

3838782176388

Net weight

4.8 kg

Gross weight

5.9 kg

Product code

733140

Connected load

146 W

Filter material

Aluminium

Max. noise level

67 dB(A)re 1 pW

Number of motors

1

Number of filters

1

Dimensions (W×H×D)

53.4 × 20.8 × 30 cm

Annual energy consumption

70.7 kWh

Dimensions of packed product (W×H×D)

58 × 24 × 32.4 cm

Coal filter code (optional as separate purchase)

416912
